19
Enable WDS Check to enable the WDS function.
Add WDS AP This is where you enter the MAC address of the peer AP’s wireless interface that you
are connecting to.
Function buttons for this setting block:
Apply Changes
Click to add this entry into the Current WDS AP List.
The Current WDS AP List lists the peer MAC addresses of the WDS link. Any AP with its MAC
address listed in this WDS AP list may have a WDS link to the device. You can select the entries at
the Select column and apply to the following function buttons.
Function buttons for the Current WDS AP List:
Delete Selected
Delete the selected entries from the list.
Delete All
Flush the list.
4.2.6 WPS
Although home Wi-Fi networks have become more and more popular, users still have
trouble with the initial set up of network. This obstacle forces users to use the open security
and increases the risk of eavesdropping. Therefore, The Wi-Fi Protected Setup (WPS) is
designed to ease set up of security-enabled Wi-Fi networks and subsequently network
management (Wi-Fi Protected Setup Specification 1.0h.pdf, p. 8).
The largest difference between WPS-enabled devices and legacy devices is that users do
not need the knowledge about SSID, channel and security settings, but they could still surf
in a security-enabled Wi-Fi network.
This device supports Push Button method and PIN method for WPS. The following
sub-paragraphs will describe the function of each item. The webpage is as below.
