This page allows you to use ATM ping, which generates F5 segment and end-to-end
loop-back cells to test the reachability of a segment endpoint or a connection endpoint.
Fields in this page:
Field Description
Select PVC Select the PVC channel you want to do the loop-back diagnostic.
Flow Type The ATM OAM flow type. The selection can be F5 Segment or F5 End-to-End.
Loopback Location ID The loop-back location ID field of the loop-back cell. The default value is all 1s (ones)
to indicate the endpoint of the segment or connection.
4.6.3 ADSL
This page shows the ADSL diagnostic result. Click Start button to start the ADSL
diagnostic.
