52
Community name
(write-only)
Name of the write-only community. This write-only community allows write operation
to the objects defines as read-writable in the MIB.
Function buttons in this page:
Apply Changes
Save SNMP configuration. New configuration will take effect after saving into flash
memory and rebooting the system. See section “Admin” for details.
4.5.4 Port Mapping
The DSL device provides multiple interface groups. Up to five interface groups are
supported including one default group. The LAN and WAN interfaces could be included.
Traffic coming from one interface of a group can only be flowed to the interfaces in the
same interface group. Thus, the DSL device can isolate traffic from group to group for
some application. By default, all the interfaces (LAN and WAN) belong to the default group,
and the other four groups are all empty. It is possible to assign any interface to any group
but only one group.
