47
Field Description
RIP Enable/disable RIP feature.
Function buttons for the second setting block in this page:
Apply Changes
Click to save the setting of this setting block to the system configuration
Fields on the second setting block:
Field Description
Interface The name of the interface on which you want to enable RIP.
Receive Mode Indicate the RIP version in which information must be passed to the DSL device in
order for it to be accepted into its routing table.
Send Mode Indicate the RIP version this interface will use when it sends its route information to
other devices.
Function buttons for the second setting block in this page:
Add
Add a RIP entry and the new RIP entry will be display in the table
Delete Selected Entry
Delete a selected RIP entry. The RIP entry can be selected on the Select column of
the RIP Config Table.
4.5 Advance Configuration
4.5.1 Bridging
You can enable/disable Spanning Tree Protocol and set MAC address aging time in this
page.
