1. Ensure the oven is powered ON.
2. If the Standby (OFF) Screen is showing, press the Green Power
Icon.
3. Press the Blue Menu Icon.
4. If the PIN is enabled, enter 1-3-5-7-9 to access Service Mode.
If the PIN is not enabled the Menu will appear.
A. Press and drag up to scroll to the bottom of the Menu and select “User
Options”.
B. Press and drag up to scroll down through the user options and select
“PIN Code”.
C. Select ON, enter and remember a 4-digit Pin Code and then select the
Home Icon.
D. Now press the Blue Menu Icon and enter 1-3-5-7-9 to access Service
Mode.
5. Ensure the Software Version displayed is less than the version being
installed. Press the Home Icon and proceed to program loading.
6. Select “Software Version”.
7. Insert the USB/Flash Drive with the new rmware into the USB port.
8. A box will appear in the lower portion of the screen “Rev “xxxx”
Available Begin Update”.
9. Press this box to begin rmware update. The screen will now
display “Entering Standby Mode” for a few seconds and then the
screen will go blank. Continue to wait.
10. The screen will blink, then a few seconds later the Startup logo will
appear. Underneath will appear the word “Updating” along with a
progress bar. Continue to wait. Note: DO NOT remove the USB/
Flash Drive until AFTER the reboot is completed.
11. After about two minutes the words “Update Complete” will appear
and a Green “Reboot” Icon will appear. DO NOT remove the USB/
Flash Drive. Press the Green Icon.
Firmware Update Procedure
The Touch Control is designed to be updated as future technology and programming requirements change.
Should new Firmware be required follow the steps below.
Firmware Updates are available at: http://acpsolutions.com/oven-programming/
A
