©2018 ACP, Inc.
Cedar Rapids, IA 52404 Page 47 of 80
Part No. 16400033
Original Instructions
Component Overview
Testing
Removal and Replacement
10
⚠
WARNING
• High voltage capacitor must be discharged before performing these procedures. Wait at least ve (5) minutes
after shutdown of high voltage system.
• Use extreme caution when working with live circuits.
⚠
DANGER
• Disconnect Power Supply before removing any Covers or Panels.
The high voltages and currents at the lament and secondary winding of the Transformer are extremely dangerous.
• The high voltages and currents at the lament and secondary winding of the transformer are extremely dangerous.
Never make any direct voltage or current measurements at these winding. It is very dangerous to work near this
part when the oven is on, or even if this circuitry has been switched o.
• All High Voltage Capacitors must be discharged before performing this procedure.
⚠
CAUTION
• Extreme care must be taken when performing tests with line voltage applied.
• Oven is heavy.
! IMPORTANT !
FOR YOUR SAFETY
Review ALL Safety Precautions before preforming any Component Testing Procedures contained in this section.
