ACTpro 1520e and ACTpro 1500e Operating & Installation Instructions
11.0 ACTpro 1520e Installation & Tech nical Specification
The power supply is capable of delivering 2A. 1.5A is available for external locks and
readers, 0.5A for the PCB and battery.
PSU Output Voltage:
12V DC The power supply provides two 12V outputs. One is pre-wired to power
the ACT Controller. The second is available to power locks.
The full load current shared between the two outputs. ACT recommend
that a maximum of 1.5A is used to power locks and readers. The
remaining 0.5A is used by the controller and battery charging.
Total current from both outputs must not exceed 2A.
Monitoring:
Mains present The PSU MAINS PRESENT output is pre-wired to the MAINS PRESENT
input of the ACTpro 1520e Controller.
Output Voltage The PSU output voltage level is reported to the ACT Enterprise software
and on the web browser.
Tamper The enclosure lid is tamper monitored.
Note: All faults including Mains Present and Tamper are reported on the ACT
Enterprise Software and via the web browser on the ACTpro 1520e
and 1500e controller.
16
Electrical Specification:
Input Voltage 230VAC +/- 10%
Frequency 47-53 Hz
Input Fuse 625mA 250V anti-surge fuse
Output Voltage 13.65V (+/- 5%)
Max Load 2A @ 25ºC
Electronic Output fuse Yes
Battery Current ~ 0.5A for a battery discharged to ~ 10V
Battery Protections Deep Discharge/Over Charge/Reverse Polarity
