5.2 Frequency SPM-32A ... SPM-36A
5-2
Longitudinal conversion loss (LCL) to
ITU-T Recommendation O.9
Table 5-1 Longitudinal conversion loss
Maximum load for both inputs
(input signal and common mode signal)
Input level . . . . . . . . . . . . . . . . . . . . . + 30 dBm
D.C.input voltage . . . . . . . . . . 60 V from Z
out
≥ 600 Ω
5.2 Frequency
Frequency range
SPM-32A . . . . . . . . . . . . . . . . 50 Hz to 620 kHz
SPM-33A/-34A/-35A
. . . . . . . . . . . 50 Hz to 2 MHz
SPM-36A . . . . . . . . . . . . . . . . 50 Hz to 3.5 MHz
Frequency setting
– Manually using keypad; resolution. . . . . . . . . 1 Hz
– Automatically using AFC
SPM-32A
> 40 dB
—
SPM-33A/-34A/-35A
> 30 dB
—
SPM-36A > 25 dB
Frequency range/Hz 50 100 620 k 1.62 M 2 M 3 M 3.5 M
