4.1 Overview SPM-32A ... SPM-36A
Z/Ω
The input impedance, Z, = 75 Ω
The input impedance, Z, = 150 Ω
(or 120, 124, 135 or 140 Ω depending on
the version)
The input impedance, Z, = 600 Ω
INPUT
Toggles between the selected input
impedance Z and high input impedance
(∞)
This key sequence toggles between the
balanced (BAL) and the coaxial input
(UNBAL).
"TEST & CONFIG": This key sequence
calls up the test and service programs
(see service manual). The software
version and the options fitted are shown
in the display. Press [CLEAR] or [*] to exit
this mode (takes a few seconds) or
switch the instrument off and then on
again.
For terminating entries.
"CAL": calls up the calibration routine
1
*
75
2
*
150
3
*
600
Z/∞
Z/∞
*
BAL/UNBAL
0
*
TEST &
CONFIG
ENTER
ENTER
*
CAL
