4-14
4.1 Overview SPM-32A ... SPM-36A
STO (D14.), appears after [*] and [↑] have
been entered; "STO" and an address
are displayed alternately. By pressing
[ENTER] you can store the current
setup and result at the address shown in
the display.
WIDEBAND (C), appears when [WIDE] is pressed.
Measurements are performed using the
wideband receiver.
Display marker ( ❑ )
This marker is used to indicate which function has been
selected; the possibilities are marked on the right- and left-
hand edges of the display.
AFC
AVRG Display averaging (slow); the resolution
of the level display is 0.01 dB.
BW Shows which bandwidth has been
selected.
CHARGE Batteries are charging
EXPAND Bargraph is expanded
INPUT:U Either 75 Ω, 150 Ω or 600 Ω has been
selected as input impedance
INPUT: ∞ High input impedance
1
INPUT: BAL The balanced input has been selected
PERM.ON The auto-off function is disabled
1
The simultaneously marked impedance value is needed
during dBm display for power computation.
