NOTE: <Pre-trigger buffer> generally ranges from 1 to 20 frames.
However, the range will change accordingly if the frame rate of
MJPEG on Streaming> Video Configuration is 6 or smaller.
Check the box <Continue image upload> to upload the triggered images
during certain time or keep uploading until the trigger is off.
Select <Upload for __sec> and enter the duration in the blank.
The images of the duration will be uploading by E-mail when the audio
event occurs. The setting range is from 1 to 99999 sec. Select <Upload
during the trigger active> to make the images keep being uploaded to
E-mail during the trigger active until the event stops. Set the Image
frequency as the upload frame rate. The setting range is from 1 to 15
frames per second.
NOTE: Make sure SMTP configuration has been completed.
Refer to section Mail for further details.
Send HTTP Notification
Check this item, select the destination HTTP address, and specify the
parameters for event notifications by <Audio Detection> triggered. When
an alarm is triggered, the notification can be sent to the specified HTTP
server.
For instance, if the custom parameter is set as “action=1&group=2”, and
the HTTP server name is “http://192.168.0.1/admin.php”, the notification
will be sent to HTTP server as “http://192.168.0.1/admin.php?
action=1&group=2” when alarm is triggered.
Record Video Clip
Check this item and select a video recording storage type, <SD Card> or
<NAS> (Network-Attached Storage>. The Audio Detection recording will
be stored in microSD/SD card or the NAS when audio is detected.
Pre-trigger buffer recording function allows users to check what
happened to cause the trigger. The pre-trigger buffer time range is from
1 to 3 sec. Select <Upload for __ sec> to set the recording duration after
audio is triggered. The setting range is from 1 to 99999 sec. Select
<Upload during the trigger active> to record the triggered video until the
trigger is off.
