PID Definitions
A – 6 • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
A
2ND TRIP FT 2nd Trip With Same Fuel Trim
2ND TRIP MISF 2nd Trip With Same Misfires
2WD HIGH LGHT 2 Wheel Drive High Indicator Light
3-2 SFT 3-2 Downshift
3-2 SFT ENABLE 3-2 Downshift Solenoid Enable
3-2 SHIFT 3-2 Shift Time
3-2 SOL PWM 3-2 Downshift Solenoid PWM
3-4 ERROR 3-4 Shift Time Error
3-4 SFT 3-4 Shift Time
3-4 SHIFT 3-4 Shift Time
3-4APT HICEL 3-4 Adapt High Cell
3-4APT LOCEL 3-4 Adapt Low Cell
3RD GEAR SW 3rd Gear Switch
3X ENG ACT 3x Engine Speed Activity
4-3 SHIFT 4-3 Shift Time
4C CLUTCH ST 4C Clutch State
4C PRESS SW 4C Pressure Switch
4C SOL 4C Solenoid
4TH GEAR SW 4th Gear Switch
4WD 4 Wheel Drive
4WD HIGH LIGHT 4 Wheel Drive High Indicator Light
4WD LOW Low Speed WD
4WD LOW LIGHT 4 Wheel Drive Low Indicator Light
4WD MODE 4-wheel Drive Mode Signal
4X BETWEEN CAM 4X Refrence Between Cam Counter
4X REF CNT 4X Reference Pulse Counter
4X4L Low Speed 4WD
5V REF A 5 Volts Reference A
5V REF B 5 Volts Reference B
5V REF AUX Auxillary 5 Volt Output
5V REF PRI Primary 5 Volt Output
A.I.R. PUMP Air Injection Reactor Pump Relay Control
A/C CLCH REL Air Conditioning Clutch Relay
A/C CLUTCH Air Conditioning Clutch
A/C CLUTCH RLY Air Conditioning Clutch Relay
A/C COMMAND Commanded A/C
A/C COMPRESSOR Air Conditioning Compressor
A/C CUTOUT RLY Air Conditioning Cutout Relay
A/C EVAP A/C Evaporative Temperature
A/C PRES A/C Pressure
A/C PRESS A/C Pressure A/D
A/C PSI DISAB A/C Psi Disable
A/C RELAY Air Conditioning Clutch Relay
A/C REQ A/C Requested
A/C REQUEST SW Air Conditioning Requested
A/C RLY COM Air Conditioning Relay Command
A/C RLY DR H Air Conditioning Relay Driver High
A/C RLY DR L Air Conditioning Relay Driver Low
A/C RLY OSG Air Conditioning Relay Circuit Open/Short To Ground
A/C RLY STP Air Conditioning Relay Circuit To Volts
A/C SELECT SW Air Conditioning Select Switch
A/C SLUGGING A/C Slugging
A/C STATUS A/C Status
A/D INPUT A/D Input
PID
Extended Description
