Wall Controller Options
Wall Controller Options
Maximum of three (3) wall controllers in below combinations is allowed on unit. See below table.
Options
Wall Controllers
C1 C2 C3
1st Option NEO
2nd Option NEO NEO
3rd Option NEO NEO LR7-1 / LC7-2
4th Option NEO LR7-1 / LC7-2
5th Option NEO LR7-1 / LC7-2 LR7-1 / LC7-2
6th Option LR7-1 / LC7-2
7th Option LR7-1 / LC7-2 LR7-1 / LC7-2
8th Option LR7-1 / LC7-2 LR7-1 / LC7-2 LR7-1 / LC7-2
NOTES
• NEO - Available in White (NTW-1000) and Black (NTB-1000) colors.
• LC7-2, LR7-1 and LM-RS-2 - Available in White and Grey colors.
• In the instance of a combination of NEO and LR7-1 / LC7-2 being connected together, the NEO will always need to be
addressed as C1.
