101
breakdown of the numbers is: "VS-3 0/02 P3", the VS-3 set to address "00"; "VS-3 0/02
P3" the corresponding PCT-8 is set to address "03"; and "VS-3 0/02 P3" the VS-3 output
to this address is Output 2. Be certain that the address perfectly matches your control
parameters.
6 Once the desired address is displayed on the keypad's LED readout, press the desired
source button (typically VIDEO). The display will read "OK". If you need a special
button to replace an existing button, please contact ADA.
7 Press SHIFT to exit the program mode.
At this point only this room's keypad source button (i.e. VIDEO) will control that particular VS-
3 and that particular VS-3 output, leaving the other keypads in the house, controlling whatever
source button they were originally programmed to control by the Delta-88. You will need to
repeat the above steps for each keypad that requires special local-only programming.
