RM244V & CS4 User Manual
Specifications: CS4
Power supply
24Vdc, 500mA from RJ45 or optional adaptor
Max. connection length
100m (CAT5 cable) or 1km with optional 24Vdc adaptor
Capsule
Back electret condenser
Polar pattern
Cardioid
Controls
Aux/Mic/Chime levels, chime DIP switches, zone/page buttons
Connectors
RJ45 to amplifier, 24Vdc power jack, 3.5mm aux in
Frequency response: -3dB
150Hz - 22kHz
Input level
Mic: -46dBV, Aux: -10dBV
Input impedance
Mic: 600 Ohms, Aux: 50k Ohms
Output level
10dBV
Output impedance: balanced
600 Ohms
S/N ratio
-60dB (all channels selected)
Interface
RS-485 control
Zone assign
4 zones or all selectable
Dimensions
460 x 140 x 115mm
Weight
670g
Specifications: RM244V
Power supply
110/230Vac, 50/60Hz (IEC)
Output power rms
240W (shared across 4 zones @ 100V)
Inputs
3 x mic/line (jack/XLR), 1 x aux (RCA)
Input sensitivity: mic
-47dBV
Input impedance: mic
5k Ohms
Input sensitivity: line
-10dBV
Input impedance: line
1k Ohms
Paging station inputs
2 x RJ45 (for optional RM-4B paging stations)
Line output (REC)
RCA
Sends: returns
Pre out, Amp in (RCA)
Channel controls
Ch1, Ch2, Ch3, Media and Aux volume
Output controls
Master volume, 4 x zone volumes & mutes
Equalizer: bass
100Hz ±10dB
Equalizer: treble
10kHz ±10dB
Phantom power
+20V (switchable inputs 1-3)
Audio source
USB/SD player, FM tuner and Bluetooth receiver
Bluetooth version
2.0
Fire alarm contacts
24V screw terminals
THD +N
<2% @ 1kHz (rated power)
Protection
Short circuit, overload, overheat
Speaker outputs
4 x 100V (modular terminal block)
Dimensions
430 x 315 x 89mm
Weight
10.4kg
