Chatper 2 - Connections
www.adcom.com
GFR-700HD Owner’s Manual
Tape Out/Aux Connections
The GFR-700HD includes two additional sets of RCA
outputs for connection to a tape recorder and/or au-
dio system. Follow these steps to connect your audio
output device to the GFR-700HD.
Connecting a Tape Recorder
1 Connect the tape recorder.
• Using RCA cables, connect the Tape outputs
on the GFR-700HD to the audio inputs on
your tape recorder.
2 Monitor the tape recording.
• Press the Tape button on the remote control
or front panel to monitor the tape output.
Connecting an Auxiliary Audio Device
1 Connect the audio device
• Using RCA cables, connect the Aux outputs
on the GFR-700HD to the line inputs on your
audio device.
• The audio signal from the Aux output will
switch according to the Video 1~4 or CD in-
put.
Notes:
• To turn the Tape Monitor
on/off, press the Tape button
on the remote control or front
panel.
• For Tape operations, see page
56.
Tape
Output
Aux
Output
