9-10 61200290L1-1G

Section 9, Transaction Language 1 (TL1) MX2800 M13 Multiplexer User Manual

RTRV-COND-{EQPT|rr|ALL}:<tid>::<ctag>;

Description Retrieves the requested alarms and conditions

MOD2 Specifies what entity type to query:

• EQPT General Equipment Unit

• rr Facility or Circuit (i.e. T1, VT1, STS1)

• ALL All entity types

TID Target ID

AID* Identifies the component to which the desired alarm pertains. Identifiers are integers

and are dependent on the entity specified in “MOD2” as follows:

for EQPT:

401 Generic

402 Control Card A

403 Control Card B

404 Power Supply A

405 Power Supply B

ALL all EQPT identifiers (default selection)

for T1:

101 DS1#1

102 DS1#2

128 DS1#28

ALL all DS1 circuits (default selection)

for T2:

201 DS2#1

202 DS2#2

207 DS2#7

ALL all DS2 circuits (default selection)

for T3:

301 DS3#1

302 DS3 (Control Card A)

303 DS3 (Control Card B)

ALL all DS3 circuits (default selection)

for ALL:

x specific identifier (e.g. 1, 28, etc.)

ALL all identifiers (default selection)

CTAG* Transaction Number (integer)

Table 9-2. TL1 Commands (Continued)
