ADTRAN MX2800 M13 - T1;E1 Line Coding; Figure 3-6. Set Multiple Menu

3-10 61200290L1-1G
Section 3, Configuration MX2800 M13 Multiplexer User Manual
NOTE
Settings should be applied following each change.
Figure 3-6. Set Multiple Menu
T1/E1 Line Coding
Set the line code for each individual T1/E1 interface to match the connected device. See Figure 3-7 on
page 3-11. The choices available for T1 are AMI and B8ZS. The choices available for E1 are AMI and
HDB3. Select Set Multiple to set a contiguous group or all of the T1s (or E1s) to the same value at the
same time. Refer to Set Multiple on page 3-9 for a description of the
Set Multiple option.
