9-28 61200290L1-1G
Section 9, Transaction Language 1 (TL1) MX2800 M13 Multiplexer User Manual
DIAGLPBKTIMEOUT ENUM One of the following:
•DISABLE
•1-MIN
•5-MINL
• 10-MIN
• 15-MIN
• 30-MIN
• 45-MIN
•1-HR
•2-HR
Identifies the amount of time before a
Diagnostic Loopback will time out
• DISABLE - timeout is disabled
• 1-MIN - timeout value is one minute
• 5-MINL - timeout value is five minutes
• 10-MIN - timeout value is ten minutes
• 15-MIN - timeout value is 15 minutes
• 30-MIN - timeout value is 30 minutes
• 45-MIN - timeout value is 45 minutes
• 1-HR - timeout value is 60 minutes
• 2-HR - timeout value is 120 minutes
DIAGRESET Y/N Y or [N] Resets Diagnostic Loopbacks
• Yes (Y) - reset the diagnostic loopback
• No (N) - do not reset the diagnostic
loopback
PSBATTERYLOWRLY Y/N Y or [N] Identifies status of Power Supply Battery
Low alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
PSCHARGERFAILRLY Y/N Y or [N] Identifies status of Power Supply Charger
Fail alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
PSFANFAILRLY Y/N Y or [N] Identifies status of Power Supply Fan Fail
alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
PSMALFNCRLY Y/N Y or [N] Identifies status of Power Supply
Malfunction alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
PSPOWERFAILRLY Y/N Y or [N] Identifies status of Power Supply Power
Fail alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
Table 9-9. TL1 Editing Data Dictionary for EQPT (Continued)
Keyword Type Domain Description
