MX2800 M13 Multiplexer User Manual Pinouts, Appendix B
61200290L1-1G B-3
NOTE
Tab le B-4 applies to both the In and Out DSX1/E1 amphenol connectors.
18 RING 18 50 TIP 18
19 RING 19 51 TIP 19
20 RING 20 52 TIP 20
21 RING 21 53 TIP 21
22 RING 22 54 TIP 22
23 RING 23 55 TIP 23
24 RING 24 56 TIP 24
25 RING 25 57 TIP 25
26 RING 26 58 TIP 26
27 RING 27 59 TIP 27
28 RING 28 60 TIP 28
29 N/A 61 N/A
30 N/A 62 N/A
31 N/A 63 N/A
32 FGND 64 FGND
Table B-4. Amphenol Pin Assignments (Continued)
Pin Function Pin Function
