Unit Installation NetVanta 3000 Series Hardware Installation Guide
62 Copyright © 2006 ADTRAN, Inc. 61200860L1-34L
3. UNIT INSTALLATION
The instructions and guidelines provided in this section cover hardware installation topics such as wall
mounting/rack mounting the unit and installing option cards. These instructions are presented as follows:
• Mounting Options on page 63
• Supplying Power to the Unit on page 66
• Installing Dial Backup and Network Interface Modules on page 68
• Installing the NetVanta VPN Accelerator Card (included in P/N 4200368L1) on page 70
• Installing a SODIMM for Expandable Memory on page 71
For information on router configuration for a specific application, refer to the quick configuration
documents provided on your ADTRAN OS System Documentation CD. For details on the command line
interface, refer to the AOS Command Reference Guide (also included on your CD).
Tools Required
The customer-provided tools required for the hardware installation of the NetVanta 3000 Series are:
• Ethernet cable
• Network cable (module dependent)
• DSX-1 cable (T1/FT1 + DSX-1 module only)
• DBU cable (dial backup functions require an optional DIM)
• Phillips-head screwdriver (rack mounting applications only)
To prevent electrical shock, do not install equipment in a wet location or during a
lightning storm.
Electronic modules can be damaged by static electrical discharge. Before handling
modules, wear an antistatic discharge wrist strap to prevent damage to electrical
components. Place modules in antistatic packing material when transporting or storing.
When working on modules, always place them on an approved antistatic mat that is
electrically grounded.
To access the command line interface (CLI) of the NetVanta 3000 Series, you will also need
a VT100 terminal or PC with terminal emulation software and a console port cable.
Instructions on how to access the CLI are given in the AOS Command Reference Guide
(provided on the ADTRAN OS System Documentation CD).
The rackmount kit for the NetVanta 3430 and NetVanta 3448 is not included in shipments
of these products. You must order the rackmount kit separately:
NetVanta 3430/3448 Series Rackmount Kit, part number 1200827E1
