ADTRAN NetVanta 3000 Series Hardware Installation Guide

Appendix A. Connector Pin Definitions NetVanta 3000 Series Hardware Installation Guide
76 Copyright © 2006 ADTRAN, Inc. 61200860L1-34K
Table A-3. CONSOLE Port (DCE) Pinouts, for NetVanta 3305
Pin Name Description
1 DCD Data Carrier Detect (output)
2 RD Receive Data (output)
3 TD Transmit Data (input)
4 DTR Data Terminal Ready (input)
5 SG Signal Ground
6 DSR Data Set Ready (output) Tied to pin 1
7 RTS Request to Send (input)
8 CTS Clear to Send (output) Tied to pin 1
9 RI Ring Indicate (output)
Connection directly to an external modem requires a cross-over cable.
Table A-4. DC Power Supply Connection (NetVanta 3205 DC Version Only)
Pin Name +24 VDC Source -48 VDC Source
1 + +24 VDC Ground (GND)
2 - Ground (GND) -48 VDC
Table A-5. ADSL Connector Pinouts
Pin Name Description
1,2 — Unused
3TADSL Tip
4 RT ADSL Ring
5,6 — Unused
