Advanced Control C220 Series - CMD and Status

Communication Protocol
C220/C420General Flux Vector Control Inverter User Manual
175
8.7 CMD and Status
Stop/start parameter（0x1000）
Parameter Add.
Parameter description
0x1000
Communication setup value(-10000 to
10000)( Decimal)
0x1001
Baud rate set value
0x1002
Running frequency
0x1003
Bus voltage
0x1004
Output voltage
0x1005
Output current
0x1006
Output power
0x1007
DI input fag
0x1008
Do output fag
For example: 0x01 0x10 0x03 0x00 0x01 crc_h crc_l(Read bus voltage).
Control command input to inverter (write-only)（0x2000）
Command Word
Address
Parameter description
0x2000
0x0001
：
Forward operation
0x0002
：
Reverse operation
0x0003
：
Forward jog
0x0004
：
Reverse jog
0x0005
：
Free stop
0x0006
：
Speed-down stop
0x0007
：
Fault reset
0x1000
：
Reset factory setting
0x1001
：
Clear the fault history
Read inverter status :( read-only)（0x3000）
Status Word Address
Status Word Function
