Advanced Control C220 Series - Group F5 Input Terminal

Parameter Description
C220/C420G General Flux Vector Control Inverter User Manual
89
5.6 Group F5 Input Terminal
The standard unit of C220/C420series inverter has 4 multifunctional digital input
terminals and 2 analog input terminals.
F5-00 DI1 terminal
function
selection
factory default
value
1（forward rotation）
F5-01 DI2 terminal
function
selection
factory default
value
2（reverse rotation）
F5-02 DI3 terminal
function
selection
factory default
value
9（fault-reset）
F5-03 DI4 terminal
function
selection
factory default
value
12（MS speed 1）
This parameter is applied to set the functions on multifunctional digital input
terminals
setup
value
function description
0 none
when there is signal input, the inverter still
has no action. The no operation function can be
set on the unused terminals so as to prevent error
1
Forward rotation
(FWD)
Control the forward rotation and reverse rotation of
the inverter via the external terminals.
