Product Information
C220/C420 General Flux Vector Control Inverter User Manual
15
2.3 Series of Inverter C220/C420
Tab.2-1 C220/C420 Inverter Model and Technical Data
Inverter model
Input
voltage(V)
Input
current
（A）
Output
current（A）
Adaptable
Motor（kW）
ADV 0.40 C220-M
Single
Phase
220V
Range:
-
15% to
20%
5.4 2.3 0.4
ADV 0.75 C220-M 8.2 4.0 0.75
ADV 1.50 C220-M 14.0 7.0 1.5
ADV 0.75 C420-M
Three Phase
380V
Range:
-
15% to
20%
3.4 2.1 0.75
ADV 1.50 C420-M 5.0 3.8 1.5
ADV 2.20 C420-M 6.2 5.1 2.2
2.4 Technical Specifications
Tab.2-2 C220/C420 Inverter Technical Specifications
Item
Specifications
Maximum
frequency
400Hz
Carrier Frequency
1k to 15kHz; the carrier frequency will be
automatically
adjusted according to the load characteristics.
Input frequency
resolution
Digital setting: 0.01Hz
Analog setting: maximum frequency ×0.1%
