C220/C420 General Flux Vector Control Inverter User Manual
16
Item
Specifications
Basic
function
Control mode
V/F control
Vector flux
control 1
Vector flux control 2
Startup torque
0.5Hz/180%（Open loop Vector flux control）
Speed adjustment
range
1：200（Open loop Vector flux control）
Speed precision
Open loop Vector flux control：≤±0.5%
Speed stability
Open loop Vector flux control
：
≤±0.3%
Overload capacity 150% rated current 60s; 180% rated current 3s
Torque hoist
Automatic torque hoist; manual torque hoist 0.1% to
30.0%
V/F curve Linear V/F, Multi-point V/F, and Square V/F
Speed-up and
Speed-down curve
Straight line or S curve speed-up and speed-down
mode; Two kinds of speed-up and speed-down
time; Speed-up and speed-
down time ranges between
0.0s
to 3000.0S.
DC brake
DC brake frequency: 0.00Hz to maximum frequency;
brake time:
0.0s to 36.0s,and brake current value:
0.0% to 100.0%.
Jog control
Jog frequency range:0.00Hz to 50.00Hz;jog
speed-up/speed-down time: 0.0s to 3000.0s.
Simple PLC and
MS speed running
It can realize a maximum of 16 segments speed
running
via the built-in PLC or control terminal.
