Advanced Control C220 Series - Group F6 Output Terminal

Parameter Description
C220/C420G General Flux Vector Control Inverter User Manual
101
F5-24
AI2 input filter
time
Factory
default
value
0.10s
Setup range
0.00s
～
10.00s
5.7 Group F6 Output Terminal
The standard unit of C220/C420series inverter has a multifunctional digital
input terminal , multifunctional relay output terminal and analog output terminal,
F6-00
Control board RELAY 1 output
selection
factory
default value
2
F6-02 Y1 output selection
factory
default value
1
The multifunctional digital output terminal function is for selection as follows
setup
value
Function Description
0 None no function
1 In running
Express the inverter is running with output frequency (0
value as option) given ON signal
2
Fault
output
The inverter is in trouble to output ON signal
3
Frequency
Refer to function code F7-22
、
F7-23 for details
