2.9 Guide to Selection of Brake Components
Tab.2-5 Selection of Inverter Brake Components
Inverter Model
Recommend
ed Power of
Brake
Resistor
Recommende
d Resistance
of Brake
Resistor
Brake
Unit
ADV 0.40 C220-M
0.3KW
≥300Ω
Built-in
as
standard
ADV 0.75 C220-M
0.3KW
≥300Ω
ADV 1.50 C220-M
0.6KW
≥150Ω
ADV 0.75 C420-M
0.3KW
≥300Ω
ADV 1.50 C420-M
0.3KW
≥300Ω
ADV 2.20 C420-M
0.3KW
≥300Ω
Caution: ×2 refers to two braking units paralleled with their respective brake resistor;
the meaning of ×3 is the same with ×2.
