Advanced Control C220 Series - Group F4 Motor Parameters

Parameter Description
C220/C420G General Flux Vector Control Inverter User Manual
85
need to adjust, and the filter time can be increased in case of huge speed fluctuation,
In case of oscillation of motor ,,this parameter shall be decreased properly.,
The time constant of speed loop filter is low, and the output torque on the inverter
may be change a lot, but its response is quick.
F3-20
Torque upper
limit
source
factory default
value
0
setup
range
0 F3-21
1
AI1
2
AI2
3 Communication setup
F3-21
Torque upper
limit
factory default
value
180%
setup range
0%
～
200%
F3-20 is used to select the setup source of torque upper limit,when setting via the
analog value,100% of the analog input setup corresponds to F3-21,and the setup
100% of F3-21 corresponds to the rated torque of the motor matching the inverter
5.5 Group F4 Motor Parameters
F4-00
Motor tuning
selection
factory default
value
0
setup
0
none
