Advanced Control C220 Series - Group F2 V;F Control Parameters

Parameter Description
C220/C420G General Flux Vector Control Inverter User Manual
75
3
Select speed-down time 4
（
F7-07/F7-08
）
When the application situation has no electrical source, taking advantage of this
function makes motor speed down to zero in deceleration mode, meanwhile, the
inverter can restart in recovery time
5.3 Group F2 V/F Control Parameters
This group function is only for V/F control（F0-03＝2）, not for the vector control.
V/F control is applicable to the general loads such as fan and pump or the
applications where one inverter drives multiple motors or the inverter power is one
level lower or higher than the motor power
F2-00
Curve setup
factory default
value
0
setup range
0
straight V/F curve
1
multiple point V/F curve
2
square VF curve
The fan and pump load can select square V/F control
0: straight V/F curve, it is suitable for common constant torque load
1: multiple point V/F curve,it is suitable for the special loads such as dehydrator and
centrifugal machine.
2: square V/F curve. it is suitable for the centrifugal loads such as fan and pump.
F2-01
Torque boost
factory default
3.0%
