C220/C420G General Flux Vector Control Inverter User Manual
80
5.4 Group F3 Vector Control Parameters
Group F2 function code is only for the vector control, that is to say , F0-03＝0
shown active, F0-03＝1shown inactive.
F3-00
Switching
frequency F1
factory default
value
10.00Hz
setup range
1.00Hz～400.00Hz
F3-01
Switching width
W1
factory default
value
5.00Hz
setup range
0.00Hz～400.00Hz
F3-02
Switching
frequency F2
factory default
value
50.00Hz
setup range
10.00Hz～400.00Hz
F3-03
Switching width
W2
factory default
value
5.00Hz
setup range
0.00Hz～400.00Hz
F3-04
Medium
Frequency
Speed
proportional
gain
factory default
value
120
setup range
10
～
1000
F3-05
Medium
Frequency
Speed Integration
time
factory default
value
1.20s
