Advanced Control C220 Series - Page 91

Parameter Description
C220/C420G General Flux Vector Control Inverter User Manual
90
setup
value
function description
2
Reverse rotation
(REV)
3
Three-line mode
running control
This terminal is used to confirm that the inverter
running mode is three-line control mode For
detailed description, please refer to F5-11 three-line
control mode function code.
4
Forward rotation
Jog
(FJOG)
FJOG refers to Jog forward rotation, while RJOG
refers to Jog reverse rotation. For details regarding
frequency and Jog acceleration/deceleration time
during the Jog running, refer to F7-00, F7-01 and
F7-02 function codes.
5
Reverse rotation
Jog
(RJOG)
6 Terminal UP
When the frequency is given by the external
terminals, it is used as increment and decrement
commands of frequency modification When the
frequency source is set to digital setup, it can be
used to adjust the setup frequency.
7 Terminal DOWN
8 Free stop
The inverter locks the output, and the motor stop
process is beyond the inverter control. It is the
general method adopted when there is huge load
and no requirement for the stop time.
This mode is the same as the meaning of coast to
stop as described in F7-26.
9
Fault reset
(RESET)
External fault reset function. It is the same as the
function of RESET key on the keyboard. Using this
function can realize long-distance fault reset.
10
Running pause
The inverter decelerates to stop, but all the running
