Advanced Control C220 Series - Page 25

Product Information
C220/C420 General Flux Vector Control Inverter User Manual
24
Model
Mounting
Hole
Physical Dimension
Diameter of
Mounting
Hole (mm)
A
(mm)
B
(mm)
H
(mm)
W
(mm)
D
(mm)
ADV 0.40 C220-M
70 120 130 80 128.3 φ4.5
ADV 0.75 C220-M
ADV 1.50 C220-M
ADV 0.75 C420-M
82 149 158 91 138 φ4.5
ADV 1.50 C420-M
ADV 2.20 C420-M
