www.advancedco.com
www.advancedco.com
5
OUT- OUT+ IN- IN+
AMP1
OUT- OUT+ IN- IN+
AMP2
+24V GND +24V GND
POWER
B A B A
RS485
AMP-1
A+ A- B- B+
AMP-2
A+ A- B- B+
INPUTS
IN1 GND IN 2 GND IN3 GND
TROUBLE
COM NO NC
Figure 1 – AV-VBM and AV-VB Backbox
AV-AMP-80
Audio Amplifier Module
AX-PSU-6
Power Supply Charger
