7.3 MECHANICAL SCHEMATIC : AIR-COOLED : 5 - 20 TON MODELS
WITH PROPELLER FANS
AIR-COOLED CONDENSER w/FANS
(5-ton model uses single fan)
COOLANT PUMP
TO PROCESS
SENSOR PROBE
TO PROCESS
PORT CONNECTION
MAKE-UP PORT
CONNECTION
MAKE-UP
SOLENOID VALVE
LEVEL SWITCH
FROM PROCESS
PORT CONNECTION
RESERVOIR TANK
EXPANSION VALVE
EVAPORATOR
SERVICE LID AND FILL PORT
REFRIGERANT
SIGHT GLASS
LIQUID LINE
SOLENOID VALVE
FILTER-DRIER
SERVICE
VALVE
HOT GAS
BYPASS VALVE
(not included onmodels with
Digital Scroll Compressors)
COMPRESSOR
CPT
COOLANT PRESSURE
TRANSMITTER
HPT
HIGH PRESSURE
TRANSMITTER
LPT
LOW PRESSURE
TRANSMITTER
