Chapter 4 System Configuration
The following table will show the logic true and false of output actions.
Output Action
True action
(the logic result value
from the Execution stage is
logic True)
False action
(the logic result value from the
Execution stage is logic False)
AO Change the analog output value Keep current status
DO
Output True value Output False value
Output False value Output True value
Counter Channel
(DI_Counter)
Start counter counting Stop counter counting
Stop counter counting Start counter counting
Reset counter Do nothing
Pulse Output
Generate continuous pulse train
Keep current statusGenerate finite pulses
Stop pulse generation
Timer
Start counting time
Stop counting time and reset
timer value to zero
Stop counting time and reset
timer value to zero
Start counting time
Internal Flag
Assign True value to flag Assign False value to flag
Assign False value to flag Assign True value to flag
Remote Message
Send message to target
device
Do nothing
Internal Counter Setting
(Counter)
Increase 1 count to counter
Do nothing
Reset counter
