Advantech ADAM-6266 User Manual

141 ADAM-6200 User Manual
Appendix A I/O Modbus Mapping Table
A.1.8 ADAM-6266 4-ch Relay Output Module with 4-ch DI
Address (0X):
40037 – 40038 0
Set Incremental Pulse
R/W
40039 – 40040 1 R/W
40041 – 40042 2 R/W
40043 – 40044 3 R/W
40045 – 40046 4 R/W
40047 – 40048 5 R/W
40303 All DO Value R/W
40305 0 - 15 GCL Internal Flag Value R/W
Address (0X) Channel Description Attribute
00001 0
DI Value
Read
00002 1 Read
00003 2 Read
00004 3 Read
00017 0
DO Value
R/W
00018 1 R/W
00019 2 R/W
00020 3 R/W
00033 0
Counter Start (1) / Stop (0)
R/W
00034 1 R/W
00035 2 R/W
00036 3 R/W
00037 0
Clear Counter (1)
Write
00038 1 Write
00039 2 Write
00040 3 Write
00041 0
Clear Overflow
R/W
00042 1 R/W
00043 2 R/W
00044 3 R/W
00045 0
DI Latch Status
R/W
00046 1 R/W
00047 2 R/W
00048 3 R/W
