Appendix A I/O Modbus Mapping Table
A.1.3 ADAM-6224 4-ch Isolated Analog Output Module
Address (0X):
Address (4X):
Address (0X) Channel Description Attribute
00001 0
DI Value
Read
00002 1 Read
00003 2 Read
00004 3 Read
00301 0
Clear GCL Counter
Write
00302 1 Write
00303 2 Write
00304 3 Write
00305 4 Write
00306 5 Write
00307 6 Write
00308 7 Write
Address (4X) Channel Description Attribute
40001 0
AO Value
R/W
40002 1 R/W
40003 2 R/W
40004 3 R/W
40101 – 40102 0
AO Status
Read
40103 – 40104 1 Read
40105 – 40106 2 Read
40107 – 40108 3 Read
40111 0
DI Event Status
Read
40112 1 Read
40113 2 Read
40114 3 Read
40201 0
Type Code
R/W
40202 1 R/W
40203 2 R/W
40204 3 R/W
40301 All DI Value Read
40305 0 – 15 GCL Internal Flag Value R/W
40411 0
Safety Value
R/W
40412 1 R/W
40413 2 R/W
40414 3 R/W
