Note:
1. Users can configure the High alarm value in the ADAM.NET utility. When AI
value is higher than the High alarm, this bit will be 1.
2. Users can configure the Low alarm value in the ADAM.NET utility. When AI
value is lower than the Low alarm, this bit will be 1.
3. The value definition of AI Status
4. Type code table
40221 All AI Channel Enable R/W
40305 0 - 15 GCL Internal Flag Value R/W
Bit Description
0 Failed to provide AI value (UART timeout)
1 Over Range
2 Under Range
3 Open Circuit (Burnout)
7 AD Converter failed
9 Zero/Span Calibration Error
Input Range Type Code (HEX)
+/- 10V 0x0143
+/- 5 V 0x0142
+/- 1 V 0x0140
+/- 500 mV 0x0104
+/- 150 mV 0x0103
+/- 20 mA 0x0181
0 ~ 20 mA 0x0182
4 ~ 20 mA 0x0180
