B.14 HDD LED Connector (JFP2)
B.15 ATX Soft Power Switch (JFP1)
B.16 SNMP SM_BUS Bus Connector (JFP2)
Table B.15: HDD LED Connector (JFP2)
Pin Signal
2HDD_LED+
5 SATA_LED+
2
5
Table B.16: ATX Soft Power Switch (JFP1)
Pin Signal
3 PANSWIN#
6GND
3
6
Table B.17: SM Bus Connector (JFP2)
Pin Signal
8 W83782G_SDAT
11 W83782G_SCLK
8
11
