Advantech AIMB-785 - Pcie X16 Expansion Slot (PCIEX16_1)

23 AIMB-785 User Manual
Chapter 2 Connecting Peripherals
2.16 PCIe x16 Expansion Slot (PCIEX16_1)
The AIMB-785 provides a PCIe x16 slot for users to install an add-on peripheral card
for extension requirements.
2.17 PCIEX4_1 ~ PCIEX4_3
PCIe x16_1
PCIe x4_1
PCIe x4_3
PCIe x4_2
