EKI-1511X/1512X User Manual 46
5.1 Overview
The EKI-1510X series serial device server can be configured through a web inter-
face. By using a standard web browser, the same procedure as with the Windows
configuration utility can be used. In the browser’s address field, enter the IP Address
of your EKI-1510X series serial device server. The default IP setting is 10.0.0.1, but
you should use the IP which you have previously assigned for this device. Once the
IP is entered, you will be presented with the following windows.
5.2 Accessing the Web Page
By Configuration utility
Note! Before using the web-based configuration, make sure your host PC
Ethernet network IP domain is as same as the serial device server, or it
can establish the TCP connection with the serial device server.
Note! All new configurations will take effect after rebooting. The reboot func-
tion is located on the main menu of the Web Configuration.
