1.3 Specifications
Communications
Standard
IEEE 802.3, 802.3u, 802.3x
IEEE 802.1d, 802.1p, 802.1Q, 802.1w
LAN
10/100Base-TX
Transmission Distance
Up to 100m (4-wire Cat.5e, Cat.6 RJ-45 cable
suggested)
Transmission Speed
Up to 100Mbps
Interface
Connectors
8 x RJ-45
6-pin terminal block (Power & Relay)
LED Indicators
System: PWR1, PWR2, R.M., P-Fail
Copper: Link/Activity, Speed
Network Management
Configuration
Web browser, SNMP v1/v2c
VLAN
IEEE 802.1Q, Port-based VLAN
Redundancy
ADVANTECH X-Ring (Recovery time < 10ms),
Dual Homing, Couple Ring, and
802.1w/d RSTP/STP
Security
IP Access Security
Traffic Control
IGMP Snooping/Query for multicast group
management, Rate limit and storm control
Diagnostics
Port Mirroring, SNTP, System log, E-Mail Alert,
SNMP Trap, RMON
Power
Power Consumption
7.6 Watts max. @ 48 V
DC
6.3 Watts max. @ 24 V
AC
/ 60Hz
Power Input
2 x Unregulated +12 ~ 48 V
DC, 24VAC (18~30V)
Relay Output
1 Relay alarm output
Mechanism
Dimensions (WxHxD)
59.6 x 152 x 105 mm
Enclosure
IP30, metal shell with solid mounting
kits
Mounting
DIN-rail, wall-mount
EKI-2548I_Manual_ed2 4
