2.5 Mounting
The EKI-2548I supports two mounting methods: DIN-rail & Wall mountings.
2.5.1 Wall Mounting
EKI-2548I can be wall-mounted by using the included mounting kit. Then, hang on the
EKI-2548I to the nails on the wall.
First, use the screws included in the package to combine the EKI-2548I and metal
mounting kit. And then you can install the device firmly via the components, please see
Figure 2.5 as below.
Figure 2.5-1 Combine the Metal Mounting Kit
EKI-2548I_Manual_ed2 14
