6 PCA-6145B/6145L User's Manual
Jumpers and connectors
Connectors on the board link it to external devices such as hard disk
drives, a keyboard, or floppy drives. In addition, the board has a
number of jumpers which you use to configure it for your applica-
tion.
The table below lists the function of each of the board jumpers and
connectors. Later sections in this chapter give instructions on setting
jumpers and detailed information on each jumper setting. Chapter 2
gives instructions for connecting external devices to your card.
PCA-6145B/PCA-6145L Jumpers
Number Function
JP1 Turbo LED
JP2 Turbo Switch
JP3 HDD LED
JP4 Clock select
JP5 Clock select
JP6 Clock select
JP7 CPU type select
JP8 CPU type select
JP9 Battery backup
JP11 CPU type select
JP13 CPU type select
JP14 Voltage selection
JP15 PS/2 mouse set
JP20, JP21 CPU type select
JP22-JP24 S.S.D. Function set
JP28 LCD Control
JP29 Watchdog timer
JP30 Rest switch
JP35-JP39 COM2 select
