Advantech PCA-6145B User Manual

Chapter 1 Hardware Configuration 9
1
1
CPU type select
In order for the system to function properly, the jumpers must be set
to accommodate the CPU installed on the CPU card.
CPU type select
CPU Type JP4 JP5 JP6 JP7 JP8 JP11 JP13 JP14 JRN1 JRN2 JRN3
Intel
DX-33(5V)
DX2-66
Intel
P24D
DX4-100
(5V)
SGS
DX4-100
AMD
5x86-133
Intel
DX4-100
AMD
DX4-100 (SV8B)
Cyrix
5x86-100
(3.3V)
11 11111 1
