22 PCA-6145B/6145L User's Manual
Power connectors J1
If you prefer not to acquire power through PCA-6145B/PCA-
6145L's backplane via the gold H-connectors, J1 also provide
power input connectors for +5 V and +12 V.
Warning! Before making the connection, make sure the
voltage is absolutely correct and matched with
the right connector.
1 + 12 V
2 GND
3 GND
4 +5 V
1 + 12 V
2 GND
3 GND
4 +5 V
1 G
N
2 +
5
3 G
N
4 +
1
12 V
5
J1
