Advantech PCA-6145B - Watchdog Timer (JP29); COM2 Setting for RS-232;422;485 (JP35~39); Battery Backup Select

12 PCA-6145B/6145L User's Manual
1 2 3
1 2 3
1 2 3
Watchdog timer (JP29)
Watchdog timer system reset/IRQ15 select (JP29)
Reset (default) IRQ15
JP29
COM2 settings for RS-232/422/485 (JP35~39)
COM2 settings for RS-232/422/485 (COM2)
RS-232 (default) RS-422 RS-485
JP35
JP36
JP37
JP38
JP39
Battery backup select
Battery Backup
(default)
JP9
1 2 3
3 2 1
6 5 4
3 2 1
6 5 4
3 2 1
6 5 4
1
1
