CPU type select
CPU Type JP4 JP5 JP6 JP7 JP8 JP11 JP13 JP14 JRN1 JRN2 JRN3
Cyrix
DX2-80
TI DX2-80
(3.3V)
AMD
DX-40
DX2-80(5V)
AMD
DX4-100
(NV8T)
(3.3 V)
Note: 1. AMD 5X86-133 JP20 ON other OFF
2. AMD DX2-80 JP21 ON other OFF
Default setting: Intel DX4-100
