CHAPTER
2
Connecting
peripherals
This chapter tells how to connect
peripherals, switches and indicators to
the PCA-6145B/PCA-6145L board. You
can access most of the connectors from
the top of the board while it is installed in
the chassis. If you have a number of cards
installed, or your chassis is very tight,
you may need to partially remove the
card to make all the connections.
